首页 » 产品中心 » 高效过滤系列 » SFU 风机过滤单元

高效过滤系列

SFU 风机过滤单元



性能特点 Features


FFU箱体采用镀铝锌板、不锈钢板、铝合金板或喷塑钢板,结构精巧坚固,便于安装;

FFU配套HEPA采用玻璃纤维滤料;高容尘量,低阻力;

功耗低,运行成本低,三档调速或无极调速控制;

采用强力风机,可在高静压下长期使用,但又可同时维持低噪音;

应用范围广,适合从10,000级到1级的各种洁净室;



Outer casing is made of galvalume, stainless steel, electrolytic sheet, galvanized sheet iron or aluminum alloy sheet;

Structure of compact, easy to install;

Low power consumption, low running costs;

With a high-capacity fan, in long-term use under high static pressure; but can also maintain a low noise;

Wide range of applications, fit a variety of clean room from FS209 DC lass10,000 ~ Class1;



应用Applications


FFU系统方便灵活,可以适用于任何结构和各等级的洁净室。它还可以用在其他净化设备上,如:可移动洁净房、洁净工作台、洁净走廊等。

FFU system is convenient and flexible, can be applied to any structureand the level of the clean room. It can also be used in other cleaningdevices, such as: portable clean room, clean bench, clean corridors and so on.



常用规格 Common Specifications


型  号

SFU-HA24

SFU-HA44

SFU-HA22

模组尺寸(mm)

1175×575×340

1175×1175×340

575×575×340

面风速(m/s)

0.35

0.55

0.35

0.55

0.35

0.55

噪  音(dB(A))

46

52

48

54

46

52

电  源

AC, 1-Ф220V/50Hz

功  耗(W)

100~120

200~245

75~90

机身重量(kg)

25

45

15

过滤器效率

99.9999.999%@0.3μm

过滤器规格(mm)

1170×570×80/70

1170×1170×80/70

570×570×80/70

过滤器重量(kg)

9.5

17

5.2

机外静压(Pa)

98



型  号

Model

SFU-HA24

SFU-HA44

SFU-HA22

箱体尺寸

Dimensions

(mm)

1175×575×340

1175×1175×340

575×575×340

面风速

Face Velocity(m/s)

0.35

0.55

0.35

0.55

0.35

0.55

噪  音

Noise sound(dB(A))

46

52

48

54

46

52

电  源

Electricity source

AC, 1-Ф220V/50Hz

功  耗

Power consumption(W)

100~120

200~245

75~90

机身重量

Body weight (kg)

25

45

15

过滤器效率

Filter efficiency

99.9999.999%@0.3μm

过滤器规格

Filter specification

(mm)

1170×570×80/70

1170×1170×80/70

570×570×80/70

过滤器重量

Filter  specification (kg)

9.5

17

5.2

机外静压

External static pressures described (Pa)

98









Model

SFU-HA24

SFU-HA44

SFU-HA22

Dimensions

(mm)

1175×575×340

1175×1175×340

575×575×340

Face Velocity(m/s)

0.35

0.55

0.35

0.55

0.35

0.55



Noise sound(dB(A))

46

52

48

54

46

52



Electricity source

AC, 1-Ф220V/50Hz



Power consumption(W)

100~120

200~245

75~90



Body weight (kg)

25

45

15



Filter efficiency

99.9999.999%@0.3μm



Filter specification

(mm)

1170×570×80/70

1170×1170×80/70

570×570×80/70



Filter  specification (kg)

9.5

17

5.2



External static pressures described (Pa)

98




1、若遇规格、结构变更,以本公司提供的新数据为准

2、本公司接受非标准规格的订货



1. If you meet specifications, structural changes, the company provides the newest data shall prevail

2.We accept the orders of non-standard specifications
